Crude Oil & Diluent Storage Terminals

Crude Oil & Diluent Storage Terminals

NAME
LOCATION
OPERATOR
STORAGE CAPACITY
(barrels)
► Manitoba
Cromer Terminal
Cromer, MB
Enbridge
2,400,000
TEML Terminal
Cromer, MB
TEML
600,000
TOTAL EST. MB CAPACITY:
3,000,000
► SASKATCHEWAN
Kerrobert Terminal
Kerrobert, SK
Enbridge
306,000
Secure Energy
420,000
Inter Pipeline
798,600
Plains Midstream
1,800,000
Lloydminster Terminal
Lloydminster, SK
Husky Energy
1,200,000
Regina Terminal
Regina, SK
Plains Midstream
375,000
South Prairie Region
Estevan, SK
TEML
450,000
TOTAL EST. SK CAPACITY:
5,300,000
► ALBERTA
Regional Operations
Northern Alberta
Enbridge
1,600,000
Athabasca Terminal
Fort McMurray, AB
3,000,000
Cheecham Terminal
Anzac, AB
2,300,000
Nipisi/Atlantic Terminal
Red Earth, AB
Plains Midstream
590,000
Edmonton Terminal
Edmonton, AB
Enbridge
13,110,000
Inter Pipeline
3,563,700 (1)
Plains Midstream
1,800,000 (2)
Trans Mountain
7,935,000 (4)
+1,315,000 (3)
Gibson
1,700,000 (1)
Edmonton North Terminal
Edmonton, AB
Pembina
850,000 (1)
Edmonton South Terminal
Edmonton, AB
Kinder Morgan (6)
5,100,000
North 40 Tank Terminal
2,150,000
Base Line Terminal
4,800,000
Canadian Diluent Hub
Fort Saskatchewan, AB
Pembina
500,000 (1)
Alberta Diluent Terminal
Keyera
342,600 (1)
Stonefell Terminal
Wolf Midstream
900,000
Access Sturgeon Terminal
350,000
Hardisty Terminal
Hardisty, AB
Enbridge
13,900,000
Flint Hills
675,000
Gibson
10,000,000 (1)
+1,000,000 (Q4/19) (3)
+1,000,000 (Q1/20) (3)
+500,000 (Q4/20) (3)
Husky Energy
3,400,000 (1)
Inter Pipeline
840,500 (1)
Spectra Energy
900,000
Keystone Hardisty Terminal
Hardisty, AB
TC Energy
2,600,000
TC Terminals
Fort Saskatchewan, AB
+1,900,000 (5)
TOTAL EST. AB CAPACITY:
CAPACITY UNDER CONSTRUCTION:
82,900,000
+3,800,000
► BRITISH COLUMBIA
Sumas Terminal
Abbotsford, BC
Trans Mountain
715,000
+175,000 (3)
Burnaby Terminal
Burnaby, BC
1,685,000 (4)
+3,900,000 (3)
Westridge Terminal
395,000
TOTAL EST. BC CAPACITY:
CAPACITY UNDER CONSTRUCTION:
2,800,000
+4,100,000
 TOTAL ESTIMATED W. CDN OIL STORAGE CAPACITY:
 CAPACITY UNDER CONSTRUCTION:
94,000,000
+7,900,000
UPDATED: SEP 1, 2019
SITE MAP: PROJECTS / MIDSTREAM / OIL STORAGE TERMINALS
NOTES:
1 INCLUDES DILUENT VOLUMES
2 INCLUDES FORT SASKATCHEWAN VOLUMES
3 UNDER CONSTRUCTION
4 INCLUDES PRODUCT VOLUMES
5 UNDER DEVELOPMENT
6 PENDING SALE TO PEMBINA PIPELINE
SOURCES:
ENBRIDGE • CRUDE STORAGE AND TERMINALS MAP
INTER PIPELINE • OIL SANDS TRANSPORTATION
INTER PIPELINE • CONVENTIONAL OIL PIPELINES
GIBSON ENERGY • HARDISTY TERMINAL
GIBSON ENERGY • EDMONTON TERMINAL
PLAINS MIDSTREAM CANADA • CRUDE OIL OPERATIONS
TUNDRA ENERGY • OUR SERVICES
HUSKY ENERGY • DOWNSTREAM OPERATIONS
TRANS MOUNTAIN • EDMONTON TERMINAL
TRANS MOUNTAIN • SUMAS TERMINAL
TRANS MOUNTAIN • BURNABY TERMINAL
WOLF MIDSTREAM • ACCESS PIPELINE
PEMBINA PIPELINE • CANADIAN DILUENT HUB (CDH) ENTERS SERVICE
KEYERA • ALBERTA DILUENT HUB
TRANSCANADA • TC TERMINALS
TRANSCANADA • KEYSTONE HARDISTY TERMINAL
